    Customizable Near IR Spectrometer 900-1700 nm Range For Accurate And Spectral Measurements

    Ask Lasest Price
    Brand Name : JINSP
    Model Number : SR50R
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 100 PCS/70-90 days
    Delivery Time : 30-50working days
    • Product Details
    • Company Profile

    Customizable Near IR Spectrometer 900-1700 nm Range For Accurate And Spectral Measurements

    High-Performance Near-infrared Fiber Modular Spectrometer


    The JINSP SR50R17 is a compact and economical near-infrared spectrometer that operates in the 900nm to 1700nm range, featuring a non-cooled InGaAs sensor with excellent sensitivity and resolution. It comes with a light source, optical fiber, and test holder, making it ideal for measuring near-infrared absorption, reflectance, and transmission to analyze materials' optical properties, such as absorption, scattering, and transmission, and to evaluate their quality and performance. Its competitive cost also positions it well for integration into industrial NIR spectrometer systems.


    Technical Parameters

    Detector

    Type

    Linear array InGaAs

    Efective Pixel

    128 (256 optional)

    Pixel Size

    50μm*250μm

    Sensing Area

    6.4mm*0.25mm

    Optical
    Parameters

    Wavelength Range

    900nm-1700nm

    Optical Resolution

    6.5nm (@25μm)

    Entrance Slit Width

    5μm, 10μm, 25μm, 50μm (customizable)

    Incident Light Interface

    SMA905 fiber interface, free space

    Electrical
    Parameters

    Integration Time

    1ms-5s

    Data Output Interface

    USB2.0, UART

    ADC Bit Depth

    16-bit

    Power Supply

    5V

    Operating Current

    <1A

    Operating Temperature

    10°C~40°C

    Storage Temperature

    -20°C~60°C

    Operating Humidity

    90%RH (no condensation)

    Physical
    Parameters

    Dimensions

    77mm*67mm*36mm

    Weight

    0.4kg

    Technical Features:

    • Lightweight and small in size, this device is easy to carry and handle.
    • The gold-coated lens provides excellent near-infrared reflectance, ensuring dependable and accurate operation.
    • It can be connected via USB or UART to share spectral data, which simplifies its incorporation into various systems and equipment.

    Typical Applications

    • Moisture content measurement, waste water testing
    • Detection of substances such as fat, oil, protein, fiber etc.
    • Grain and fodder quality testing
    • Measurement ofpharmaceutical mixturecomponents

    Support and Services:

    The Near infrared spectrometer provides high-performance spectral measurements in a portable and affordable package. Our product technical support and services include:

    - Expert technical assistance and troubleshooting

    - Comprehensive product documentation and user manuals

    - Software updates and upgrades

    OEM miniature spectrometer high-sensitivity fiber spectrometer optic spectrometerOEM miniature spectrometer high-sensitivity fiber spectrometer optic spectrometer

    OEM miniature spectrometer high-sensitivity fiber spectrometer optic spectrometer

    Customizable Near IR Spectrometer 900-1700 nm Range For Accurate And Spectral Measurements

    Company Introduction:

    JINSP Company Limited originates from Tsinghua University and has 17 years of experience in developing spectroscopic technology.As a leading supplier of spectroscopic technology, JINSP Technology offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, customs, and fiber optic spectrometers. Our products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.

    OEM miniature spectrometer high-sensitivity fiber spectrometer optic spectrometerOEM miniature spectrometer high-sensitivity fiber spectrometer optic spectrometer

    Customizable Near IR Spectrometer 900-1700 nm Range For Accurate And Spectral Measurements

    FAQ

    Q1:This is the first time I use,is it easy to operate?

    A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.

    Also our technicians will offer professional tecnical opearation meetings.

    Q2:Can you offer a operation training?

    A2:Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local

    support( installation , training, debugging, maintenance ).

    Q3:How to receive a best price in the shortest time?

    A3:When you send us an inquiry,please kindly offer details with wavelength,detector,effective pixels,focal length

    and so on.We will send you quotation with details soon to your email.

    Q4:If the spectrometer has problem in my place,how could I do?

    A4:The spectrometer has one year warranty.If it breaks down,our technician will figure out what the problem maybe,

    according to client's feedback.We can repair for free within one year warranty.

    Q5:Which payment can be acceptable ?

    A5:We could accept the payment by T/T, Paypal, Western Union,L/C, etc.
